Specifications -
Max. wheel diameter: 250 mm
Maximum wheel width: 242 mm
Max. module: 6 mm
Min. number of teeth: 2
Milling cutter diameter x width: 130×155 mm
Adjustment of milling-spindle: 115 mm
Milling slide swivelling: 240 mm
Table diameter: 250 mm
Table hole: 63 mm
Distance table / counter stay: 565 mm
Distance table / middle of spindle: 380 mm
Center distance between workpiece-tool min./max.: 10 – 210
